The weight per unit of electricity is very light. Statistics show that the weight of hydraulic pump and hydraulic motor per unit power is only the generator. 1/10 of the motor, hydraulic pump and hydraulic motor can be as small as 0.0025N/W, and the generator and motor with the same power can be about 0.03N/W. As for size, the former is about 12%~13% of the latter. In terms of output force, it is easy to get extremely high pressure hydraulic fluid with a pump, which will produce great force after being delivered to the hydraulic cylinder. Therefore, hydraulic technology has the advantages of light weight Shenyang Manufacturer The outstanding characteristics of small size and large output are conducive to the miniaturization and miniaturization of mechanical equipment and its control system for high-power operation. Flexible and convenient layout. The configuration of hydraulic components is not restricted by the strict space position, and it is easy to pass according to the needs of the machine. The connection of all parts of the system is realized through pipes, and the layout setting has great flexibility special-purpose Sweeper cycloidal hydraulic motor Soft, which can form a complex system that is difficult to form by other methods.

The oil distribution sleeve is synchronized with the rotor, so that the rotor rotates once, and the seven oil distribution holes on the housing are closed 840 times by the twelve diaphragms of the oil distribution sleeve, while the rotor and stator form the largest and smallest closed cavities respectively 1420 times, collectively referred to as the seal cavity. In the circle of the oil distribution hole of the closed housing, the oil inlet and outlet of the rotor have three chambers respectively, one Shenyang Sweeper cycloidal hydraulic motor The cavity is closed. When the rotor is transferred from the smallest enclosed cavity to the next largest enclosed cavity, before the rotor is transferred from the largest enclosed cavity to the next smallest enclosed cavity, oil is supplied to four cavities and three cavities special-purpose Sweeper cycloidal hydraulic motor Drain the oil.

As far as energy conversion is concerned, the hydraulic pump and hydraulic motor are connected as reversible hydraulic components, and the working fluid can be input into any kind of hydraulic pump to make it become a hydraulic motor; On the contrary, when the main shaft of the hydraulic motor rotates under the action of external force Sweeper cycloidal hydraulic motor Manufacturer It can also become a hydraulic pump. Because they all have the same basic structural elements, namely sealed and recyclable volume and corresponding distribution mechanism. However, the working environment of hydraulic motor and hydraulic pump is different special-purpose Sweeper cycloidal hydraulic motor The performance requirements are also different. Therefore, there are many differences between the hydraulic motor and the hydraulic pump of the same model. The first hydraulic motor should be positive and negative, so its internal structure should be symmetrical; The speed range of the motor must be large enough, especially its minimum stable speed must have certain requirements.

1. Air intrusion. When the air intrudes into the hydraulic system, it has a large volume in the low-pressure area. When it enters the high-pressure area, it is compressed, and the volume suddenly decreases. When it enters the low-pressure area, the volume suddenly increases, resulting in a sudden change in the bubble volume, that is, "explosion" phenomenon, resulting in noise. Solution: Generally, the hydraulic cylinder is equipped with an exhaust device special-purpose Sweeper cycloidal hydraulic motor Exhaust. In addition, a common method is to exhaust the actuator several times during the fast full stroke after startup. 2. The quality of the hydraulic pump or motor is poor. The quality of the hydraulic pump is poor, the accuracy does not fully meet the technical requirements, the pressure and flow fluctuations are large, the oil trapping phenomenon has not been eliminated well, and poor sealing and poor bearing quality are the main reasons for the noise. In use, due to wear of hydraulic pump parts, excessive clearance, insufficient flow Shenyang Manufacturer The force is easy to fluctuate and will also produce noise.
