orbit motor The production process of the cycloidal motor is very critical. The following is an example of a cycloidal motor with a diameter of 50 mm produced by a company to explain the production process of the cycloidal motor in detail.

Step 1: Prepare materials. Cycloidal motor is usually composed of rotor, retainer, output shaft, transition gear, housing and other parts, and different kinds of materials are required for the manufacturing of these parts. In this case, the rotor and retainer are made of steel, the output shaft is made of stainless steel, the transition wheel is made of graphite, and the housing is made of aluminum alloy.

Step 2: processing design. For each part of cycloidal motor, CAD drawing shall be carried out. After computer simulation debugging, mold design shall be carried out. Mold design includes mold structure design, mold parts design, mold processing technology design and other specific contents. According to the requirements of this case, the mold design needs to ensure the precision and stability of the cycloidal motor.

Step 3: Manufacturing. According to the mold design, select the processing equipment suitable for your own production, such as CNC lathe, front end machine, milling machine, etc. The production and manufacturing of each component shall be carried out in strict accordance with the design requirements, and at the same time, continuous inspection and commissioning shall be carried out to ensure the processing accuracy and quality.

Step 4: Install. Assemble the processed parts. Pay attention to the fitting accuracy and firmness of the parts during installation to prevent mismatch or over tightening. After installation, the cycloidal motor shall be inspected, and the test data must meet the requirements of relevant indicators

Step 5: quality inspection. Carry out comprehensive inspection on cycloidal motor, including surface inspection, dimension measurement, rotation resistance test, static load test, etc., to ensure that the product can meet the performance and quality indicators required by customers.

Through the above process flow, the production process of cycloidal motor is completed from raw materials to finished products, and then to quality inspection. In this case, it took 12 hours to produce the cycloidal motor with a diameter of 50 mm. The process flow has gone through several stages, such as preliminary preparation, processing design, production manufacturing, installation and quality inspection. The whole process is tight, efficient and stable, and the finished product has met the standards, specifications and customer needs.
