How to select hydraulic motor of agricultural machinery

2021-05-20 11:43:03
second

Select new system for design scheme Hydraulic motor of agricultural machinery , or in the current system Hydraulic motor When looking for alternatives, we should consider other factors besides the output power (torque, speed ratio) regulations. In many cases, referring to the past application work experience (that is, under the similar application standards, what motors were used successfully, and what motors were selected failed), it is a shortcut for preliminary review of motors. When there is no previous application experience to refer to, the following elements must be taken into account:

1. Duty cycle system

2. Type of hydraulic oil

3. Minimum total flow and larger total flow

4. Scope of work pressure

5. System type: open system or closed test system

6. Operating temperature, system operating temperature and refrigeration system

7. Oil pump type: gear oil pump, gear pump or axial plunger pump

8. Overpressure protection: valve close to hydraulic motor

9. Rate exceeds load maintenance

10. Axial load and radial load

The working load cycle system and the rate exceeding the load maintenance are two key factors that are often ignored. When the generating rate exceeds the load standard, the motor is in the working condition of the oil pump, and the torque borne by the motor connecting shaft is likely to be twice that under all normal working conditions. If the above conditions are ignored, the motor will be damaged.

Another key factor to consider when pairing systems is a workload cycling system. If it is specified that the motor is overloaded for a long time and has a relatively satisfactory service life, then the torque and speed ratio index values obtained from the commercial sample plate can only meet the application requirements, and it is not enough. It is necessary to select the product series whose performance parameters are higher than the first gear. Similarly, if the motor often works at a low level, you can select a sample version to get a product series with lower performance parameters. An example is the use of hydraulic motor to drive the winch. The electric winch manufacturer uses the WhiteRS series motor. Although the main working parameters exceed the technical parameters obtained from the sample, everything can still work normally. Because the motor application level is often very low, and the delay time of each operation is very short, no matter the characteristics or service life can be relatively satisfactory. The motors selected in that way can significantly reduce the purchase cost.

When the air displacement and torque of the motor come from the condition of "two possibilities", the working load cycle system, working pressure and total flow become the decision elements for selecting the most suitable hydraulic motor to give the working standard.

     White motor How much is the minimum speed ratio of?

Generally, when the motor operates at a speed ratio of 10r/min or lower, crawling and unstable operation are likely to occur. Because the change of internal leakage of the motors of HB, DR and DT series is very small when the total flow is small, White Enterprise strongly recommends the motors of the above three series to be used in places where the stability of the motor in low speed gear is high. Friends also strongly recommend the use of a motor with as large an exhaust volume as possible, so that the total flow of the motor can be improved. Standards beneficial to the low-speed gear characteristics of the motor: 1) stable load; 2) throttle valve at the inlet and outlet of the motor or backpressure type with an increase of 0.25MPa; 3) minimum viscosity of 160SUS (34.5cSt) at operating temperature.

To ensure excellent low gear operation. Propose the customer to carry out experimental certification for the selected motor under specific working standards.

How many motors can be connected in series in one application?

Under normal conditions, only one motor inlet is likely to have a large working pressure, which does not exceed the allowable continuous working pressure of the motor with the lowest rated working pressure in the serial oil passage. There is no limit to the total number of motors that can be connected in series in the system. In order to make the motors in serial operation work better, it is strongly recommended to select the motors of HB, DR and DT series products, and external leakage oil pipeline should be connected.
