1、 The speed, in r/min, indicates the number of revolutions per minute of the motor output shaft. Each displacement motor has a fixed speed range, beyond which the motor is easy to be damaged. The motor speed is too low, which is easy to cause creeping.

2、 Flow, in L/min, indicates Price of cycloidal hydraulic motor Volume of hydraulic oil discharged per minute. Each type of motor has a relatively fixed flow value. If the flow value exceeds this value, the motor speed will be too high.

3、 Displacement, in ml/r, indicates the volume of hydraulic oil discharged by Yiyi per revolution of the motor. The displacement of each motor is fixed, i.e orbit motor It is a constant displacement motor.

4、 Pressure, in MPa, indicates the force applied per unit area. The pressure regulation of the motor can realize stepless pressure regulation. Generally speaking, the pressure Zui borne by the motor is 20MPa, which is too high and the motor load is too large, so it is easy to be damaged.

5、 Torque, in Nm, indicates the magnitude of the force per unit length. The torque value of each motor varies according to the pressure it is subjected to, but it cannot exceed the Zui maximum value of the torque applied to the motor. If the motor exceeds the Zui maximum value, it will be overloaded, and the motor will be quickly damaged.

6、 Back pressure, in MPa, indicates the pressure on the oil drain port. Excessive back pressure will damage the internal seal of the motor.

7、 Radial load, in N, indicates the radial force on the motor output shaft. The large radial load of each motor can be found on the sample plate.

8、 False seepage, a small amount of hydraulic oil oozing from the motor joint surface. Model of cycloidal hydraulic motor When the temperature rises to a certain level during operation, the surface of the motor oozes rapidly, but then no more oozes. This kind of condition does not affect the use of the motor.

9、 Volume efficiency, the actual utilization rate of the volume cavity inside the motor. It is one of the indexes to distinguish motor performance.

10、 Mechanical efficiency, Bm cycloidal hydraulic motor The ratio of actual torque to theoretical torque. It is one of the indexes to distinguish motor performance.
